304 Stainless Steel C Channel 6m To 12m Hot Rolled

304 Stainless Steel C Channel 6m To 12m Hot Rolled
304 Stainless Steel C Channel 6m To 12m Hot Rolled 304 Stainless Steel C Channel 6m To 12m Hot Rolled

Large Image :  304 Stainless Steel C Channel 6m To 12m Hot Rolled

Product Details:
Place of Origin: China
Brand Name: PUXIANG, TSINGSHAN
Certification: ISO,CE
Model Number: C Channel
Payment & Shipping Terms:
Minimum Order Quantity: 2 ton
Price: US$1980-US$2180
Delivery Time: 10-15 working days after receiveing advance payment
Payment Terms: T/T, T/T + L/C
Supply Ability: 1000ton/month
Contact Now

304 Stainless Steel C Channel 6m To 12m Hot Rolled

Description
Description: Stainless Steel C-Channel Grade: 304
Size: 50x37mm To 400x104mm Length: 6m To 12m Or As Required
Applications: Frame Work, Braces, Supports, Marine, Food, Etc. Package: Standard Export Package
Highlight:

304 stainless steel c channel

,

stainless steel c channel 6m

,

Hot Rolled stainless c channel

304 C Shape Stainless Steel Channel, 304 Stainless Steel C-Channel

304 Stainless Channel, is a hot rolled stainless channel shape with inside radius corners that is ideal for all structural applications where greater strength and superior corrosion resistance is required. 304 Stainless Channel has a durable dull, grainy mill finish that is widely used for all types of fabrication projects that are exposed to the elements - chemical, acidic, fresh water, and salt water environments.

Item No. H (mm) W (mm) Thickness (mm) Cross Section (cm²) Weight/pc (kg/m)
5# 50 37 4.5 6.928 5.438
6.3# 63 40 4.8 8.451 6.634
6.5# 65 40 4.3 / 6.709
8# 80 43 5 10.248 8.045
10# 100 48 5.3 12.748 10.007
12# 120 53 5.5 / 12.059
12.6 126 53 5.5 15.692 12.319
14#a 140 58 6 18.516 14.535
14#b 140 60 8 21.316 16.733
16#a 160 63 6.5 21.962 17.24
16#b 160 65 8.5 25.162 19.752
18#a 180 68 7 25.699 20.174
18#b 180 70 9 29.299 23
20#a 200 73 7 28.837 22.637
20#b 200 75 9 32.837 25.777
22#a 220 77 7 31.846 24.999
22#b 220 79 9 36.246 28.453
25#a 250 78 7 34.917 27.41
25#b 250 80 9 39.917 31.335
25#c 250 82 11 44.917 35.26
28#a 280 82 7.5 40.034 31.427
28#b 280 84 9.5 45.634 35.832
28#c 280 86 11.5 51.234 40.219
30#a 300 85 7.5 / 34.463
30#b 300 87 9.5 / 39.173
30#c 300 89 11.5 / 43.883
32#a 320 88 8 48.513 38.083
32#b 320 90 10 54.913 43.107
32#c 320 92 12 61.313 48.131
36#a 360 96 9 60.91 47.814
36#b 360 98 11 68.11 53.466
36#c 360 100 13 75.31 59.118
40#a 400 100 10.5 75.068 58.928
40#b 400 102 12.5 83.068 65.208
40#c 400 104 14.5 91.068 71.488


304 Stainless Steel C Channel 6m To 12m Hot Rolled 0

304 Stainless Steel C Channel 6m To 12m Hot Rolled 1
304 Stainless Steel C Channel 6m To 12m Hot Rolled 2
