GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm

GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm
GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm

Large Image :  GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm

Product Details:
Place of Origin: China
Brand Name: PUXIANG, TSINGSHAN
Certification: ISO,CE
Model Number: H Beam/ I Beam
Payment & Shipping Terms:
Minimum Order Quantity: 2 ton
Price: US$1980-US$2180
Delivery Time: 10-15 working days after receiveing advance payment
Payment Terms: T/T, T/T + L/C
Supply Ability: 1000ton/month
Contact Now

GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm

Description
Description: Stainless Steel H Beam Grade: 201, 304, 316 Etc.
Size: 100x100mm To 502x470mm Length: 6m To 12m Or As Required
Type: Tapered And Non-Tapered Package: Standard Export Package
Highlight:

GB/T 11263-2010 Stainless Steel Profiles

,

Stainless Steel Profiles 100mm

,

201 hot rolled i beams

GB/T 11263-2010 Hot Rolled I-Beams with Parallel Flange Surfaces

H-section steel is a kind of economical section and high-efficiency section with more optimized cross-sectional area distribution and more reasonable strength-to-weight ratio. It is named because its section is the same as the English letter "H". Since the various parts of the H-shaped steel are arranged at right angles, the H-shaped steel has the advantages of strong bending resistance, simple construction, cost saving and light structure in all directions.

         GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm 0                GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm 1
Item Geometry Weight
h (mm) b (mm) tw(mm) tf (mm) r1(mm) (kg/m)
HW 100x100 100 100 6 8 8 16.9
HW 125x125 125 125 6.5 9 8 23.5
HW 150x150 150 150 7 10 8 31.1
HW 175x175 175 175 7.5 11 13 40.4
HW 200x200 200 200 8 12 13 49.9
HW 200x204 200 204 12 12 13 56.2
HW 244x252 244 252 11 11 13 63.8
HW 250x250 250 250 9 14 13 71.8
HW 250x255 250 255 14 14 13 81.6
HW 294x302 294 302 12 12 13 83.4
HW 300x300 300 300 10 15 13 93
HW 300x305 300 305 15 15 13 104.8
HW 338x351 338 351 13 13 13 104.6
HW 344x348 344 348 10 16 13 113
HW 344x354 344 354 16 16 13 129.3
HW 350x350 350 350 12 19 13 134.9
HW 350x357 350 357 19 19 13 154.2
HW 388x402 388 402 15 15 22 140.1
HW 394x398 394 398 11 18 22 146.6
HW 394x405 394 405 18 18 22 168.3
HW 400x400 400 400 13 21 22 171.7
HW 400x408 400 408 21 21 22 196.8
HW 414x405 414 405 18 28 22 231.9
HW 428x407 428 407 20 35 22 283.1
HW 458x417 458 417 30 50 22 415
HW 492x465 492 465 15 20 22 202.5
HW 498x432 498 432 45 70 22 604.5
HW 502x465 502 465 15 25 22 239
HW 502x470 502 470 20 25 22 258.7

GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm 2


GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm 3
GB/T 11263-2010 Stainless Steel Profiles Hot Rolled I Beams HW100x100mm To HW502x470mm 4



Tag:

Hot Rolled Stainless Steel Profiles,

304 ss profile,

5" Stainless Steel Profiles
